bi-dierction video with bi-direction audio fiber transmitter manufacturer from China Dailianxu Engineering Co.,Ltd

bi-dierction video with bi-direction audio fiber transmitter

Payment Terms:	T/T,L/C,WU
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Means of Transport: Air

Brand Name: DLX

Delivery Date: 10days

8ch bi-dierction video+8ch bi-direction audio+8ch bi-direction data over single fiber

8ch bi-dierction video+8ch bi-direction audio+8ch bi-direction data over single fiber,S

0km,60km optional.

FEATURES

One multimode or single mode fiber

Modularized and industrialized design ensuring reliability and flexibility

Large capacity of gigabit optical fiber transmission allowing of easy upgrade

10 digit coding and non-compression video transmission

Large-scale Proprietary IC Core

Auto PAL/NTSC/SECAM Compatible

Support 24bits DVD format, High Dynamic Range video and Stereo audio

Multi-services Flexible Configuration on the Same Platform

Indicators for Power Supply, Video, Optic-link and Data-loop

Free from In-field Adjustment

Flexible and Easy Mount

Protection against lightening strike and surge

Transmission distance: 2KM(multi-mode),20km,40km,60km,80KM,100km optional (Single-mode)

SPECIFICATIONS

Video

Channel : 1-16

Connector: BNC

Bandwidth: 8MHz

Quantization: 10 bits

DG: 1% typical

DP: 1 typical

SNR: >67dB

Audio Input/output impedance: 600ohm(balanced) or 1000ohm(unbalanced)

Digitization: 24bit

Bandwidth: 20Hz to 20KHz

Nonlinear distortion coefficient: ≤ 1%

SNR: >85dB

Connector: Terminal Plug with screw clamps/RCA

Data

Interface Type: RS-232/485/422, Manchester, Biphase

Operation Mode: Full-duplex/Half-duplex

Date Rate: DC-384Kbps/DC-2Mbps

BER: <10E-9

Connector: RJ45/ Terminal Plug with screw clamps

Environmental

Operation temperature: -30°C~+75°C

Storage temperature: -40°C~+85°C

Relative humidity: 0-95% Non-Condensing

MTBF: ≥10e5 hours

Power Supply: AC 100V~260V

Level 3 Anti-lightning, TI chip, Goldplated PCB board (optional), All Industry grade components , ESD protection design
